Dual Reel Take-Up Machine With Automatic Bobbin Change

Place of Origin : Wuxi

Brand Name : HNT

Certification : ISO9001:2008, CE, High-tech enterprise

MOQ : 1 set

Price : negotiable

Packaging Details : according to customer's requirements

Delivery Time : 30-120 days

Payment Terms : T/T, L/C

Bobbin Change Type : Automatic Bobbin Change

Application Bobbin Size Range : 400-1250mm

Line Speed : Max. 1000m/min

Wire Dia. : 5-14mm

After-sales service provided : Engineers available to service machinery overseas

Warranty : 12 Months

Contact Now

Auto Dual Reel Take-up



Description

  1. Auto Double coiling take-up is suitable for spooling with bobbin diameter from 500mm to 1250mm.
  2. Each model supports 2 types of spools, and 400 taper spools are compatible for this series.
  3. Spool change are automatic,
  4. Loading and unloading can be switched between manual mode and automatic mode
  5. The machine is controlled by PLC and has a touch screen interface, can be integrated to any extrusion line.
  6. Power:AC variable frequency motor；
  7. Traverse:Servo Motor control；
  8. Bobbin Change: Automatically switch between empty and full disks, the length of the changeable disk can be preset, and the meter can be automatically changed (with independent meter, encoder meter).
  9. Change length error: ﹥10m;
  10. Changeover success rate:98%；
  11. Loading and Unloading of the bobbin: Manually, equipped with upper and lower guide roller brackets；
  12. Control description: This machine is operated by independent electric box, reserved emergency stop, linkage interface, meter output interface.

Technical Parameter

Model Compatible Wire Diameter (mm) Max production speed (m/min) Spool outer diameter (mm) Spool width (mm)
500 5    1000 400 - 500 375
630 5 500 - 630 475
800 7 630 - 800 600
1000 7 800 - 1000 750
1250 14 1000 - 1250 950





Dual Reel Take-Up Machine With Automatic Bobbin Change
